Passenger Seat Backrest – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Position the backrest onto the rear mudguard. Fit the fixings but do not fully tighten
at this stage.
1. Fixings
2. Backrest
