Triumph Rocket 3 GT 2021 - Page 1247

1209
4. Position the rear undertray tabs to the slots in the rear panel. push rearwards to
locate fully into the slots.
1. Rear undertray
2. Tabs
5. Secure the undertray to the battery box and tighten the fixings to 3 Nm.
1. Undertray
2. Fixings
