1252
11. Position the rear undertray tabs to the slots in the rear panel. push rearwards to
locate fully into the slots.
12. Secure the undertray to the battery box and tighten the fixings to 3 Nm.
1. Undertray
2. Fixings
13. Close the passenger left and right hand footrests.
1. Rear Undertray
2. Tabs
