Pinpoint Tests - Keyless ECM
Power Supply Rail Overvoltage/Undervoltage
Fault
Possible cause
Action
C1001
C1002
Main power supply over Voltage
Main power supply under Voltage
Blown fuse
Short circuit to ground or open circuit
Charging system fault
Disconnect Keyless ECM
connectors and proceed to
pinpoint test 1:
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Keyless ECM pin 12
- Keyless ECM pin 4
- Ignition relay pin 3
- Battery subharness pin 1
- Battery positive terminal
- Battery negative terminal
OK
Proceed to test 2
Faulty
Rectify fault, proceed to test 4
2
Check cable for short circuit:
- Keyless ECM pin 12 to ground
OK
Proceed to test 3
Short circuit
Locate and rectify wiring fault,
proceed to test 4
3
Check cable continuity:
- Battery positive terminal to
Keyless ECM pin 12
OK
Reconnect harness and
proceed to test 4
Open Circuit
Locate and rectify wiring fault,
proceed to test 4
4
Check fuse integrity:
- Fuse box, fuse 1:
- Main 40 Amp fuse
OK
Proceed to test 5
Faulty
Replace blown fuse(s),
proceed to test 5
5
Reconnect harness, clear fault code
and run engine. Measure the
battery voltage while the engine is
running
Greater than
14.6 V or
Less than
13.9 V
Contact Triumph service
13.9 V –
14.6 V
Action complete – quit test
