Triumph Rocket 3 GT 2021 - Page 136

108
4. Release the four clips and detach the secondary air injection (SAI) pipe from the reed
valve covers and the air filter element box.
1. Clips
2. SAI pipe to reed valves
3. SAI pipe to air filter box
5. Carefully manoeuvre the secondary air injection pipe to the front of the engine.
NOTICE
Note how the air filter element box is secured to the frame for installation.
Not the orientation of the air filter element for installation.
