Triumph Rocket 3 GT 2021 - Page 1360

1322
Pinpoint Tests
Test
Result
Action
1
Verify instrument panel is
operating. Have the key close to the
motorcycle to turn the ignition ON
OK
Disconnect keyless ECM and
instruments connector and
proceed to test 3
Faulty
Proceed to test 2
2
Check cable and terminal integrity:
- Keyless ECM pin 5
- Keyless ECM pin 13
- Instruments pin 25
- Instruments pin 24
OK
Proceed to test 3
Faulty
Rectify fault, proceed to test 8
3
Check cable for short circuit:
- Keyless ECM pin 5 to ground
- Keyless ECM pin 13 to ground
OK
Proceed to test 4
Short circuit
Locate and rectify wiring fault,
proceed to test 7
4
Check cable continuity:
- Instruments pin 27 to battery
positive terminal
- Instruments pin 26 to ground
OK
Proceed to test 5
Faulty
Rectify fault, proceed to test 7
5
Check cable continuity:
- Keyless ECM pin 13 to
instrument pin 25
- Keyless ECM pin 5 to instrument
pin 24
OK
Proceed to test 6
Open circuit
Locate and rectify wiring fault,
proceed to test 7
6
Check cable for short circuit:
- Keyless ECM pin 13 to Keyless
ECM pin 5
OK
Proceed to test 7
Short circuit
Locate and rectify wiring fault,
proceed to test 7
7
Check fuse integrity:
- Fuse box, fuse 4
OK
Proceed to test 8
Faulty
Replace blown fuse, proceed
to test 8
8
Reconnect harness, clear fault code
and run engine to verify fault
cleared
OK
Action complete – quit test
Fault still
present
Contact Triumph service
