4. Release the fixings and remove and slide the upper cover rearwards for removal.
Discard the fixings.
1. Fixings (M5 x 14 mm)
2. Fixings (M5 x 12 mm)
3. Upper cover
4. Slot on lower cover
5. Lug on upper cover
NOTICE
Note the routing of the rear direction indicator harnesses for installation.
The harness for the right hand direction indicator can be identified by the red tape on
it.
