1384
2. Release the fixing and manoeuvre the cover to release the retaining lug and remove
the cover.
1. Fixing
2. Cover
3. Retaining lug
4. Instruments harness
3. Disconnect the electrical connector from the instruments.
4. Release the fixings and remove the instruments.
1. Fixing (left hand side shown)
2. Instruments
