9. Hold the key against the LF antenna location until the Triumph diagnostic tool
reports the key has been successfully paired.
If pairing does not occur immediately, slowly adjust the position of the key to the LF
antenna (keeping it in close proximity) until the pairing is achieved.
10. Click Add to pair another key in the same way or click Finish to end the process.
Guidelines - Replacing a Lost Smart Key
This instruction provides a brief outline of the process for pairing a replacement smart
key, in the event that the original smart key has been lost. The instruction assumes the
motorcycle is in its delivered condition, with one smart key and two passive keys paired.
1. Obtain all available motorcycle keys from the owner.
2. Power the motorcycle ON using one of the passive keys.
3. Connect the Triumph diagnostic tool.
4. Select Re-Register All keys.
The pairing of the passive key used to power the motorcycle ON is retained.
The other two keys are registered as inactive.
5. Pair the replacement smart key.
6. Press the smart key button to lock the new smart key to the keyless ECM.
7. Pair the passive key that was NOT used to power the motorcycle ON.
The motorcycle now has two passive keys and the replacement smart key paired.
The original smart key is stored as an erased key in the keyless ECM memory. If the
original smart key is later found, it can be paired and reactivated by following the
'Adding a Second Smart Key' procedure (see Guidelines - Adding a Second Smart
Key).
