Triumph Rocket 3 GT 2021 - Page 161

133
3. The coolant level must be between the MAX (upper line) and MIN (lower line) marks
in the expansion tank.
1. MAX mark
2. MIN mark
3. Expansion tank cap
4. Remove the coolant expansion tank cap from the coolant expansion tank.
5. Add coolant mixture through the filler opening until the level reaches the MAX mark.
6. Refit the coolant expansion tank cap.
