150
6. Insert service tool T3880502 into the camshaft slots. Make sure the tool is centrally
located between the camshafts.
2
1. T3880502 - Camshaft timing bar
2. Camshaft slots
With the camshaft alignment marks, at the sprocket end, pointing inwards and the
camshaft timing bar in the slots of the camshaft, adjustment is not required.
If the camshaft timing bar will not fit into the camshaft slots, adjust the camshaft timing
as described in the procedure below.
