Triumph Rocket 3 GT 2021 - Page 192

164
4. Release the fixings and remove the rear bevel box badge. Discard the fixings.
1. Fixings
2. Badge
5. Remove the bearing sleeve and oil seal.
6. Coat the needle rollers with Castrol grease. Make sure the needle rollers turn so that
the grease is distributed over the entire circumference of the internal parts.
1. Oil seal
2. Bearing sleeve
3. Needle roller bearing
