192
10. Remove the bleed tube.
11. Replace the bleed screw cap.
12. Make sure the float for the brake fluid reservoir is in the reservoir.
13. Fit the insert to the diaphragm seal.
14. Fit the diaphragm and insert assembly to the reservoir cap. Make sure the holes for
the fixings are correctly aligned.
15. Fit the fixings into the cap and diaphragm seal assembly.
1. Insert
2. Diaphragm seal
3. Reservoir cap
4. Fixings
If the master cylinder reservoir cap screws are over tightened this can result in a brake
fluid leak.
A dangerous riding condition leading to loss of motorcycle control and an accident
could result if this warning is ignored.
