263
NOTICE
Note the orientation of the baffle plate, the two oil strainers and their O-rings for
installation.
Note the orientation of the oil pick-up and its retaining plate filter for installation.
11. Remove the baffle plate and the filters for cleaning.
1. Fixings
2. Oil strainers
3. Pick-up filter
4. Retaining plate
5. Sump
12. Clean the surfaces of the crankcase and the sump cover using a lint free cloth.
