312
23. Remove service tool T3880501 from the crankcase.
1. T3880501 - Crankshaft Locking Pin
2. Alignment mark
Always check that service tool T3880502 has been removed before rotating the
engine. Severe damage will result to the camshafts or service tool T3880502 if engine
rotation is attempted with the tool installed.
24. Rotate the engine until the remaining two sprocket bolts are accessible.
