319
4. Lightly tap the cylinder head with a rubber mallet to break the seal of the gasket.
5. Remove the cylinder head and the camshaft drive chain assembly. Discard the cylinder
head gasket.
The gasket between the barrel and the crankcase must also be replaced if the cylinder
head has been removed.
Failure to replace the gasket may result in an engine oil leak between the barrel and
crankcase.
5. To hold the barrel in position, fit service tool T3880518 to the cylinder head and
secure using two of the original bolts for the cylinder head
6. Remove the barrel (see Barrels - Removal) and discard the gasket.
Cylinder Head – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Make sure all traces of fluid (coolant, oil etc.) are removed from the threaded holes in
the crankcase. Should any fluid remain in any of the threaded holes, severe crankcase
damage could result from hydraulic locking of head bolts on assembly of the engine.
