Valves and Valve Stem Seals - Removal from the Cylinder Head
1. Remove each valve from the cylinder head using a valve spring compressor. The
compressor must act on the top cup to allow removal of the valve collets.
Valve Removal
2. Once the collets are released, remove the following items:
• collets;
• valve spring cap;
• valve spring;
• valve stem oil seal;
• spring platform;
• valve (de-burr before removal).
