2. Remove the spacers.
3. Lightly tap the barrels with a rubber mallet to break the seal of the gasket.
Support the pistons as the barrels are removed to prevent piston damage.
Note the position of the locating dowels for installation.
4. Mark each piston and cylinder bore with a number to make sure that the pistons are
fitted into their original cylinders on installation.
5. Carefully remove the barrel and piston assembly. Take care to make sure that the
connecting rods are not allowed to fall against the inside of the crankcase.
1. Piston alignment mark
2. T3880518-Spacer
