378
Steel Plate Inspection
Bend/warp
Check all plates for bend and warp as follows:
1. Place the plate being checked on a clean surface plate and attempt to pass a feeler
gauge of the maximum service limit thickness etween the steel plate and surface
plate. If the feeler gauge can be passed beneath the steel plate at any point, renew
the plates as a
1. Steel plate
2. Feeler gauge
3. Surface plate
2. For specifications refer to Clutch and Primary Drive.
