439
6. Release the fixing and remove the dead shaft keeper plate. Discard the fixing.
1. Fixing
2. Keeper plate
3. Dead shaft
NOTICE
The keeper plate end of the dead shaft has a M6 thread within it. Use a M6 bolt to
assist the removal of the dead shaft.
Note that at the front of the balancer gear and the rear of the oil pump drive gear
there are washers that sit in a recess of the gears.
7. Fit a M6 bolt to the front dead shaft.
