457
2. Stop the engine.
3. Remove the dead shaft clamp blanking plug located on the lower crankcase above
the side stand. Discard the washer.
1. Blanking plug
2. Side stand
4. Loosen the dead shaft pinch bolt a maximum of two complete turns to allow smooth
rotation of the balancer dead shaft in the clamp.
1. Pinch bolt
