520
5. Note the position of the location dowels for the oil pump.
1. Dowels
2. Lower crankcase
6. Remove the circlip for the oil pump seal in the lower case. Discard the circlip.
NOTICE
Note the position of the oil seal, just behind groove for circlip, for installation.
7. Using a suitable tool, carefully remove the oil seal without damaging the lower
crankcase. Discard the seal.
1. Circlip
2. Oil seal
3. Lower crankcase
