532
6. Using a suitable tool, carefully fit a new oil seal without damaging the lower
crankcase.
7. Secure the oil seal with a new circlip.
1. Circlip
2. Oil seal
3. Lower crankcase
8. Fit the oil pump drive dowel.
9. Fit the oil pump drive gear and the hardened washer.
10. Secure the washer and the drive gear with a new the circlip.
1. Circlip
2. Hardened washer
3. Oil pump drive gear
4. Dowel
