3. Release the three fixings and detach the slave cylinder from the clutch cover. Make
sure the piston remains in its cylinder. Discard the slave cylinder gasket.
1. Fixings
2. Clutch slave cylinder
4. Retain the piston to the slave cylinder using a retaining tie such as a rubber band or
cable tie. Position the slave cylinder to one side.
1. Clutch slave cylinder
2. Retaining tie
