Throttle Position Sensor
Fault
Code
Possible cause
Action
P0120
Throttle position sensor 1 short circuit
to battery positive or open circuit
View and note diagnostic software
freeze frame data if available.
View and note diagnostic software
sensor data.
Make sure sensor connector is secure
Disconnect ECM and proceed to
pinpoint test 1:
P0121
Throttle position sensor 1 signal out
of range
P0122
Throttle position sensor 1 short circuit
to ground
P0220
Throttle position sensor 2 short circuit
to battery positive or open circuit
P0221
Throttle position sensor 2 signal out
of range
P0222
Throttle position sensor 2 short circuit
to ground
P2135
Throttle position sensor 1 correlation
error with throttle position sensor 2
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
All Fault Codes
- Engine ECM pin A20
- Engine ECM pin A32
P0220, PO221, PO222, P2135
- Engine ECM pin A38
- Engine ECM pin A26
OK
Disconnect sensor and
proceed to test 2
Faulty
Rectify fault, proceed to
test 5
2
Check cable for short circuit:
P0220, PO221, PO222, P2135
- Engine ECM pin A26 to ground
- Engine ECM pin A38 to ground
OK
Proceed to test 3
Short
Circuit
Locate and rectify wiring
fault, proceed to test 5
