658
Fuel Injectors
Fault
Code
Possible cause
Action
P0201
Injector 1-1 circuit malfunction
View and note diagnostic software
'freeze-frame' data if available. Make
sure relevant injector connector is
secure.
Disconnect engine ECM and proceed
to pinpoint test 1:
P0202
Injector 2-1 circuit malfunction
P0203
Injector 3-1 circuit malfunction
P0205
Injector 1-2 circuit malfunction
P0206
Injector 2-2 circuit malfunction
P0207
Injector 3-2 circuit malfunction
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
All Fault Codes
- EMS relay pin 5
- Engine Subharness connector pin 7
P0201
- Engine ECM pin C23
- Engine Subharness connector pin 1
- Injector 1-1 pins 1 and 2
P0202
- Engine ECM pin C6
- Engine Subharness connector pin 3
- Injector 1-2 pins 1 and 2
P0203
- Engine ECM pin C7
- Engine Subharness connector pin 5
- Injector 1-3 pins 1 and 2
P0205
- Engine ECM pin B7
- Engine Subharness connector pin 2
- Injector 2-1 pins 1 and 2
P0206
- Engine ECM pin B8
- Engine Subharness connector pin 4
- Injector 2-2 pins 1 and 2
P0207
- Engine ECM pin B5
- Engine Subharness connector pin 3
- Injector 2-3 pins 1 and 2
OK
Proceed to test 2
Faulty
Rectify fault, proceed to
test 7
