661
Test
Result
Action
6
Check relevant injector resistance:
- Injector pin 1 to injector pin 2
11.4
Ohms
to 12,6
Ohms
Proceed to test 7
Faulty
Renew relevant injector,
proceed to test 7
7
Reconnect harness, clear fault code and
run engine to verify fault cleared.
OK
Action complete - quit test
Fault
still
present
Contact Triumph service
1. Engine ECM Connector A
2. Engine ECM Connector C
3. Engine ECM Connector B
4. Engine Subharness (main harness side)
5. Engine Subharness (engine harness side)
6. Fuel Injectors
7. Engine
Management
System Relay
