665
Test
Result
Action
5
Check injector resistance value integrity
for the relevant fault code, P0300 will
require all terminals listed to be checked:
P0301
- Engine ECM pin C23 to EMS relay pin
5
- Engine ECM pin B7 to EMS relay pin 5
P0303
- Engine ECM pin C6 to EMS relay pin 5
- Engine ECM pin B8 to EMS relay pin 5
P0303
- Engine ECM pin C7 to EMS relay pin 5
- Engine ECM pin B5 to EMS relay pin
OK
11.4
Ohms
to 12.6
Ohms
Proceed to test 7
Faulty
Disconnect relevant
injector and proceed to test
6
6
Check relevant injector resistance:
- Injector pin 1 to injector pin 2
11.4
Ohms
to 12,6
Ohms
Proceed to test 7
Faulty
Renew relevant injector,
proceed to test 9
7
Check coil resistance value for the
relevant fault code, P0300 will require all
terminals listed to be checked:
P0301
- Engine ECM pin B33 to EMS relay pin 5
P0302
- Engine ECM pin B22 to EMS relay pin 5
P0303
- Engine ECM pin B11 to EMS relay pin 51
OK
3.0
Ohms
to 4.2
Ohms
Proceed to test 9
Faulty
Renew relevant ignition
coil, proceed to test 8
8
Check relevant ignition coil resistance:
- Ignition coil pin A-1 to ignition coil
pin B-1
OK
3.0
Ohms
to 4.2
Ohms
Proceed to test 9
Faulty
Renew relevant ignition
coil, proceed to test 9
9
Reconnect harness, clear fault code and
run engine to verify fault cleared.
OK
Action complete - quit test
Fault
still
present
Contact Triumph service
