661
Test
Result
Action
5
Check resistance value:
Engine ECM pin A08 to
- Engine ECM pin B33 (ignition coil 1
(fault code P0351))
- Engine ECM pin B22 (ignition coil 2
(fault code P0352))
- Engine ECM pin B11 (ignition coil 3
(fault code P0353))
Engine ECM pin A21 to
- Engine ECM pin B33 (ignition coil 1
(fault code P0351))
- Engine ECM pin B22 (ignition coil 2
(fault code P0352))
- Engine ECM pin B11 (ignition coil 3
(fault code P0353))
3.0 Ohms
to 4.2
Ohms
Proceed to test 6
Open
Circuit
Disconnect relevant
ignition coil and proceed to
test 6
Short
Circuit
Disconnect relevant
ignition coil and proceed to
test 6
6
Check relevant ignition coil resistance:
- Ignition coil pin 1 to ignition coil
pin 2
3.0 Ohms
to 4.2
Ohms
Proceed to test 7
Faulty
Renew relevant ignition
coil, proceed to test 7
7
Reconnect harness, clear fault code
and run engine to verify fault cleared.
OK
Action complete - quit test
Fault still
present
Contact Triumph service
