Triumph Rocket 3 GT 2021 - Page 701

663
Secondary Air Injection Valve
Fault
Code
Possible cause
Action
P0412
Secondary air injection short circuit to
ground or open circuit
View and note diagnostic tool sensor
data.
Make sure the SAI valve connector is
secure.
Disconnect engine ECM and proceed
to pinpoint test 1:
P044F
Secondary air injection short circuit to
battery positive
Disconnect engine ECM and SAI valve
and proceed to pinpoint test 5:
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Engine ECM pin B02
- EMS Relay pin 5
- SAI solenoid pin 1
- SAI solenoid pin 2
OK
Proceed to test 2 for P0412
Proceed to test 3 for P044F
Faulty
Rectify fault, proceed to
test 7
2
Check cable for short circuit:
- Engine ECM pin B02 to ground
OK
Proceed to test 4
Short
Circuit
Locate and rectify wiring
fault, proceed to test 7
3
Check cable for short circuit:
- Engine ECM pin B02 to EMS Relay
pin 5
OK
Proceed to test 5
Short
Circuit
Locate and rectify wiring
fault, proceed to test 4
4
Check cable continuity:
- EMS relay pin 5 to SAI valve pin 1
- Engine ECM pin B02 to SAI valve
pin 2
OK
Proceed to test 5
Fault still
present
Locate and rectify wiring
fault, proceed to test 7
5
Check resistance value, reconnect SAI
valve:
Engine ECM pin B02 to EMS Relay pin 5
18 Ohms
to 24
Ohms
Proceed to test 6
Open
Circuit
Disconnect SAI valve and
proceed to test 6
Short
Circuit
Disconnect SAI valve and
proceed to test 6
