668
1. Engine ECM Connector C
2. Fuel pump subharness (main harness end)
3. Fuel pump subharness (subharness end)
4. Fuel pump subharness (at fuel pump mounting plate)
5. Fuel pump harness (inside fuel tank)
6. Fuel pump harness to fuel level sensor fly lead (inside fuel tank)
7. Fuel level sensor fly lead (inside fuel tank)
8. Fuel Level Sensor
Vehicle Speed Sensor
Fault
Code
Possible cause
Action
P0500
Wheel speed sensor fault
Refer to the following ABS DTCs.
Front Wheel Sensor Open Circuit/Short Circuit
Front Wheel Sensor Abnormal Input/Losing
Contact
Rear Wheel Sensor Open Circuit/Short Circuit
Rear Wheel Sensor Abnormal Input/Losing
Contact
