694
Test
Result
Action
4
Check cable continuity:
- Fan speed controller connector pin 1
to Fuse box fuse 7
- Fan speed controller connector pin 2
to ground
- Fan speed controller connector pin 3
to Ignition relay pin 5
- Fan speed controller connector pin 4
to Engine ECU connector pin C13
OK
Proceed to test 5
Open
Circuit
Locate and rectify wiring
fault, proceed to test 5
5
Reconnect harness, clear fault code and
run diagnostic software function test to
visually verify operation of cooling fan.
OK
Action complete - quit test
Fault
still
present
Contact Triumph service
