696
Engine ECM detects Inertial Measurement Unit (IMU) circuit malfunction
Fault
Code
Possible cause
Action
P16A1
Engine ECM detects Inertial
Measurement Unit (IMU) circuit
malfunction
View and note 'freeze-frame' data if
available.
Make sure ABS modulator connector
is secure. Proceed to pinpoint test 1:
NOTICE
For this model, the Inertial Measurement Unit (IMU) circuit is incorporated in the ABS
module.
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity.
- Engine ECM pin C25
- Engine ECM pin C24
- ABS modulator pin 2
- ABS modulator pin 4
- ABS modulator pin 10
- ABS modulator pin 11
- ABS modulator pin 18
- Ignition relay pin 5
OK
Disconnect ECM and
proceed to test 2
Faulty
Rectify fault, proceed to
test 6
2
Check cable for short circuit:
- Engine ECM pin C25 to ground
- Engine ECM pin C24 to ground
OK
Disconnect ABS modulator
and proceed to test 3
Short
Circuit
Locate and rectify wiring
fault, proceed to test 5
3
Check cable for short circuit:
- ABS pin 2 to ground
- ABS pin 11 to ground
OK
Proceed to test 4
Short
Circuit
Proceed to test 5
4
Check cable continuity:
- Engine ECM pin C25 to ABS pin 2
- Engine ECM pin C24 to ABS pin 11
- ABS pin 10 to ground
- Fuse box fuse 8 to ABS pin 18
- Ignition Relay Pin 5 to ABS pin 4
OK
Proceed to test 5
Open
Circuit
Locate and rectify wiring
fault, replace relevant fuse
proceed to test 65
