716
Test
Result
Action
2
Check cable for short circuit:
- Fuel pump relay pin 5 to ground
OK
Proceed to test 3
Faulty
Rectify fault, proceed to
test 4
3
Check cable continuity:
- Fuel pump relay pin 5 to fuel pump
pin 2
- Fuel pump pin 1 to ground
OK
Proceed to test 4
Faulty
Rectify fault, proceed to
test 4
4
- Check fuse box Fuse 1 integrity
OK
Proceed to test 5
Faulty
Replace fuse, proceed to
test 5
5
Reconnect harness, clear fault code and
run engine to verify fault
cleared.
h
OK
Action complete - quit test
Fault still
present
Contact Triumph service
1. Fuse Box
2. Fuel Pump
3. Battery
4. Battery Subharness
5. Fuel pump harness (inside fuel tank)
6. Fuel pump subharness (at fuel pump mounting plate)
7. Fuel pump subharness (subharness end)
8. Fuel pump subharness (main harness end)
9. Fuel Pump Relay
10. Engine ECM Connector A
11. Left Hand switch Housing Subharness (main harness side)
12. Left Hand switch Housing Subharness (subharness side)
13. Left Hand Switch Housing
