Triumph Rocket 3 GT 2021 - Page 775

737
8. Raise the front of the fuel tank 50 - 100 mm and disconnect the fuel tank breather
hose from the evaporative cannister.
1. Roll over valve hose
2. Purge valve haose
3. Evaporative canister
9. To release the double check clip, ease the latch away from the connector until the
release buttons are exposed.
1. Locked Position
2. Unlocked Position
