53
Connecting Rods
Connecting Rod Small End Diameter
25.032 - 25.045 mm (standard)
25.055 mm (service limit)
Connecting Rod Big End Diameter
55.500-55.518 mm (standard)
Connecting Rod Big End Side Clearance
0.15 -0.30 mm (standard)
0.5 mm (service limit)
Crankshaft
Crankshaft Big End Journal Diameter
52.458 - 52.472 mm (standard)
52.434 mm (service limit)
Crankshaft Big End Bearing Clearance
0.034 -0.066 mm (standard)
0.071 mm (service limit)
Crankshaft Number 1 Main Journal Diameter (front
of engine)
52.471 - 52.495 mm (standard)
52.44 mm (service limit)
Crankshaft Number 2, 3 and 4 Main Journal
Diameter
52.479 - 52.495 mm (standard)
52.455 mm (service limit)
Crankshaft Main Bearing Clearance
0.02 -0.046 mm (standard)
0.078 mm (service limit)
Crankshaft End Float
0.1 -0.35 mm (standard)
0.5 mm (service limit)
Crankshaft Run-out
0.035 mm (standard)
0.05 mm (service limit)
