773
4. Fit the four fixings and tighten to 8 Nm.
1. Fixings
2. Plenum base
3. Crankcase breather pipe
4. Air temperature sensor
5. Fit a new seal to the plenum base.
6. Fit the plenum cover to the base and tighten the plenum cover fixings in the
following two stages:
Stage 1
7. Tighten the fixings one to four in the sequence shown to 4 Nm.
