Triumph Rocket 3 GT 2021 - Page 819

781
4. Detach the purge valve hose and remove the throttle bodies.
1. Purge valve hose (yellow)
2. MAP sensor hose (green)
3. Throttle body
5. If required, release the fixings and remove the transition piece.
1. Fixings
2. Transition piece
