855
1. Attach the evaporative canister to its rubber grommets on the ignition coil bracket.
1. Grommets
2. Bracket
2. Attach the evaporative canister bracket to the evaporative canister. Do not fully
tighten the fixings at this stage.
3. Fit the evaporative canister bracket to the fuel tank mounting and tighten the new
lock nuts to 22 Nm.
4. Tighten the evaporative canister fixings to 5 Nm.
5. Attach the brake line P-clip to the evaporative cannister bracket and tighten the
fixing to 5 Nm.
