858
2. Detach the purge valve from the evaporative canister bracket.
3. Using service tool T3880207 release the clamp and detach the secondary air injection
hose from the purge valve.
4. Disconnect the electrical connector and remove the purge valve.
1. Purge valve
2. Evaporative canister bracket
3. Clamp
4. Electrical connector
Purge Control Valve - Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
