2. Position a container below the engine and radiator to collect the displaced coolant.
3. Turn the radiator cap cover anticlockwise and remove.
4. Release the fixing and remove the coolant pressure cap.
1. Cover
2. Fixing
3. Coolant pressure cap
5. Pivot the radiator lower surround and remove the coolant drain plug from clutch
cover, located next to the water pump cover, to drain the coolant. Discard the sealing
washer.
1. Drain plug
2. Sealing washer
3. Water pump cover
4. Clutch cover
