887
7. Remove the engine oil filler cap and check for contamination of the engine oil caused
by coolant escaping into the engine sump.
8. Release the pressure from the coolant test kit using the pressure release valve.
9. Detach the service tool T3880176 bayonet type adapter from the coolant filler neck.
10. Fit the coolant pressure cap to the radiator filler neck and tighten the fixing to 1 Nm.
11. Align the alignment mark on the radiator cap cover to alignment mark on the
radiator cowl and it the radiator cap cover. Turn the cap cover clockwise to secure.
1. Fixing
2. Alignment mark
Coolant Pressure Cap Test
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
