Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Thoroughly clean the thermostat cover and clutch cover mating faces.
2. Make sure the two hollow dowels are located as noted for removal.
3. Position a new gasket to the clutch cover.
4. Fit the thermostat with the bypass hole positioned as noted for removal.
5. Fit the thermostat cover and tighten the fixings to 9 Nm.
1. Fixings
2. Cover
3. Gasket
4. Thermostat
5. Bypass hole
6. Hollow dowels
Perform the following operations:
1. Radiator - Installation
