906
5. Remove the fork from service tool T3880171 and, using a slide hammer action to
release the oil seal and bushes from the outer tube. Separate the inner and outer
tubes, leaving the seals and bushes in place on the inner tube. Note the relative
positions and orientation of all bushes and seals before removal.
1. Inner tube
2. Outer tube
6. To allow the removal of the seals and bushes, carefully remove the upper bush from
the inner tube.
1. Inner tube
2. Upper bush
