Trix 66839 - Page 17

17
Important: Changes in the settings market with * for the Selectrix mode of operation automatically lead to
changes in the DCC mode of operation and versa!
CV
Discription DCC Value
1 * Adress 1 - 127
3 Acceleration delay 1 - 127
4 Braking delay 1 - 127
5 * Maximum speed 1 - 7
17 Extended address (upper part) CV 29, bit 5=1
18 Extended address (lover part) CV 29, bit 5=1
29 bit 0: Travel direction polarity reversal
bit 1: number of speed levels 14/28
bit 2: DCC operation with braking block
DCC-, Selectrix- and DC power operation
bit 5: addresse size 7 bit / 14 bit
Value
0 / 1
0 / 2
0 / 4
0 / 32
***
0. 1, 2, 3, 4, 5,
6, 7, 32, 34, 35,
36, 37, 38, 39
34
Assignment of output Aux2 (value is the same as the function, example: 2 = F2) 0 - 8
35
Assignment of output Aux3 (value is the same as the function, example: 3 = F3) 0 - 8
49
* Pulse width for motor control 0 - 3
50
* Rule variant 0 - 3
51
* bit 0: Motor polarity reversal
bit 1: Headlight polarity reversing
bit 2: Track polarity reversal
0 / 1
0 / 2
0 / 4
0 - 7
*** The values for the desired settings must be added.
