*** The values for the desired settings must be added.
Important: Changes in the settings market with ( * ) for the
Selectrix mode of operation automatically lead to changes in
the DCC mode of operation and versa!
CV
Discription DCC Value Factory
Setting
Selectrix
Value
1 * address 1 - 127 3 1 - 99
3 acceleration delay 0 - 127 3 1 - 7
4 braking delay 0 - 127 3 1 - 7
5 * maximum speed 1 - 7 7 1 - 7
17 extendet address (upper part) CV 29, bit 5=1 255 not necessary
18 extendet address (lower part) CV 29, bit 5=1 255 not necessary
29 bit 0: Travel direction polarity reversal
bit 1: number of speed levels 14/28
bit 2: DCC Operation with braking Block
DCC-, Selectrix and DC power operation
bit 5: address size 7 bit / 14 bit
Value
0 / 1
0 / 2
0 / 4
0 / 32
***
0. 1, 2, 3, 4,
5, 6, 7, 32,
34, 35, 36, 37,
38, 39
6 not
necessary
49 * pulse width for motor control 0 - 3 1 1 - 4
50 * ule variant 0 - 3 2 1 - 4
51 * bit 0: motor polarity reversal
bit 1: lighting polarity reversal
bit 2: track polarity reversal
0 / 1
0 / 2
0 / 4
***
0 - 7
4 not necessary
