Trotec PAE 51 Operating Manual

3 EN
Operating manual – air cooler PAE 51
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Note
Do not operate the device without an inserted air filter!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
Behaviour in the event of an emergency
1. Switch the device off.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.
Information about the device
Description of the device
The air cooler lowers the room temperature to a comfortable
degree by evaporation-based cooling.
The device is filled with cold water or optionally with ice cubes
and/or ice packs in order to cool down the incoming warm air
at the evaporation filter and to blow out the cold air thus
generated via the fan.
Besides its cooling function, the device can also be used for air
freshening: thanks to an integrated air filter and the evaporation
filter's honeycomb structure, the sucked-in air is filtered and
humidified.
The fan speed can be set to four stages.
The discharge direction of the cooled air can be manually
adjusted via the ventilation flaps as well as via the optionally
selectable automatic swing mode.
The device has a night mode enabling ultra-silent operation at
bedtime.
The device can be operated via the control panel at the device
or via the infrared remote control.
Moreover, using the timer function, the device can be switched
off automatically with time delay.
The device can be operated in an energy-efficient manner. If
none of the operating elements have been actuated for a period
of 60s, the LEDs are automatically dimmed.

Trotec PAE 51 Specifications

General

Type	Portable evaporative air cooler
Control type	Touch
Product color	Black, White
Handles quantity	1
Number of wheels	4 wheel(s)
Carrying handle(s)	Yes
Airflow	663 m³/h
Air speed	7 m/s
Noise level	60 dB
Number of speeds	4
Water tank capacity	20 L
Timer duration (maximum)	15 h
Suitable for room area up to	60 m²
AC input voltage	220 - 240 V
Power source type	AC
AC input frequency	50 Hz
Package depth	390 mm
Package width	342 mm
Package height	897 mm
Package weight	8000 g
Air purifiers functions	Cooling, Fan
