Operation
9. Tighten the thread again. 10. Reconnect the air assist
hose.
7.6 Position of the lens
Assembly without lens Assembly with a 2.0 inch lens Assembly with a 4.0 inch lens
Notice
Make sure that the lens is placed with the convex side facing upwards.
