Operation
7.9 Options
7.9.1 JobControl Vision
With the JobControl® Vision additional option, a camera is
located at the laser working head which reads the register
marks on the plate material.
This allows distortions in the print to be detected and
compensated for. The material is cut to fit exactly.
Production times are accelerated and cost-intensive
incorrect cuts are avoided.
In JobControl®, under the Options - Hardware -
Accessories tab, the Camera option must be checked in
order to adapt the acceleration and travel distance to the
weight on the working head.
Notice
When the camera is removed, the hook can
be removed to return the speed and travel
distance to maximum.
57
