If any of these elements are changed or added to, you will need to
go through this process again.
Auto Power On/Off Switch: Set the switch to “ON” and
the subwoofer will automatically turn on when it senses any kind
of signal from the receiver/preamp. To override this feature, set the
switch to “OFF” and the subwoofer will turn on and off manually
with the power switch.
Power Switch: This turns the AC power to the subwoofer
either on or off.
Cleaning the Subwoofer
All SS Series subwoofers feature lightly textured, durable paint
finish. When needed, we suggest cleaning with a damp cloth with
water only. Do not use any kind of abrasive cleaners or detergents.
Important Safety Instructions
1. Follow all instructions and warnings in this manual.
2. Do not use this apparatus near water.
3. Clean only with a damp cloth.
4. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
5. Do not install near any heat sources such as radiators, heat
registers, stoves,
or other apparatus (including amplifiers) that
produce heat.
6. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
7. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
8. Only use attachments/accessories specified by the manufacturer.
9. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
10. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
11. Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
12. The apparatus shall not be exposed to dripping or splashing.
No objects filled with liquids, such as vases, shall be placed on the
apparatus.
13. WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
14. Where the mains plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
15. WARNING: The Class I apparatus shall be connected to a
mains socket outlet with a protective earthing connection.
16. WARNING: The 110-120V~/220-240V~ voltage selector must
be set to the correct local voltage with the proper fuse installed.
WARNING: SHOCK HAZARD - DO NOT OPEN
• Descriptions of Graphical Symbols
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
The “lightning bolt” with an “arrowhead” symbol within an equilateral
triangle alerts you to the presence on uninsulated “dangerous voltage”
within the product’s enclosure and to the fact that such voltage may
constitute a risk of electric shock to one or more persons.
The exclamation point within an equilateral triangle alerts you to the
presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.
CAUTION:
ATTENTION:
DISCONNECT POWER CORD BEFORE CHANGING FUSE.
REPLACE WITH SAME TYPE OF FUSE.
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE.
UTILIZER UN FUSIBLE DE RECHANGE DE MÊME TYPE.
APPLICABLE FOR USA CANADA OR WHERE APPROVED FOR USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE PLUG TO WIDE SLOT INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU AU FOND.
L
R
WARNI NG : SHOCK HA ZARD - DO NOT O PEN
AVIS : RISQUE DE CHOC ELECTRIQUE - NE PAS OU VRIR
ON
OFF
1 1 0- 1 2 0 V ~/ 6 0 Hz
2 2 0- 2 4 0 V ~/ 5 0 Hz
WA T T S
POWER
11 0 - 12 0 V ~, F U SE T3 . 1 5A L / 250 V
22 0 - 24 0 V ~, F U SE T1 . 6 AL / 2 50V
110-120 V~
220-240 V~
CAUTION:
DISCONNECT POWER CORD BEFORE CHANGING FUSE.
REPLACE WITH SAME TYPE OF FUSE.
ATTENTION:
DEBRANCHER AVANT DE REMPLACER LE FUSIBLE.
UTILIZER UN FUSIBLE DE RECHANGE DE MÊME TYPE.
Part # :
Serial # :
AUTO
OFF ON
0
180
PHASE
FREQUENCY
VOLUME
POWER
LOW LEVEL
INPUT
MIN MAX
40Hz 200Hz
LFE
INPUT
HIGH LEVEL
INPUT
L
R
1 5 0
